  • Suspends U bracket compatible speakers
  • Adjustable pick-up point compensates for speaker imbalance
  • Pan, tilt and rotation adjustable…on the fly

The U Tube™ speaker rigging system provides a quick, reliable and aesthetically pleasing solution for suspending U bracket compatible speakers.

The system automatically compensates for any front to back speaker imbalance, and an adjustable pick-up point compensates for any side to side imbalance. This allows the suspension stem to remain vertical.

Because the U Tube™ incorporates the same stem assembly and structural attachment methodology as the APE Hanger™, it has most of the advantages of the APE Hanger™. This is a common characteristic of all APE systems.

Please review the APE Hanger™ page for details with illustrations.

FAQs

small-divider
  • Q: What is the vertical pipe that the loudspeaker is attached to?
    A: 3/4 inch schedule 40 steel pipe. 1.05 inch outside diameter. This IS NOT thin wall conduit.
  • Q: Do you supply the 3/4inch down pipe?
    A: No, it is a User provided component. The length of this pipe determines the elevation of the loudspeaker above the floor. Since this need can range from very short to very long, it is best purchased locally by the user.
  • Q: Where can I purchase the 3/4inch down pipe?
    A: At any plumbing supply outlet or industrial supply house.
  • Q: Are your systems suitable for Outdoor installations?
    A: Our systems are intended for Indoor controlled environments only.
